Operating Instructions For TD/TAD4 Dual Fuel Burner
June 13 97 of 165 TD/TAD4 Manual Rev 4
26
1
INNER NYLON ROLLER
GA5761A
27
1
OUTER NYLON ROLLER
GA5761B
28
1
MOUNTING GASKET
GA11741
29
2
OIL ELECTRODE
IGELEC00110
30
4
SPLIT ELECTRODE BUSH
GA8264
31
1
OIL TUBE SUPPORT SPIDER
GA12370
32
2
HIGH LOW OIL NOZZLE
SEE PROD. SHEET
33
2
TWIN NOZZLE BLOCK
GA5406
34
15
1/4"BSP DOWTY 'BONDED' SEAL
SEADOW00105
35
10
MALE STUD COUPLING 10mm MMC 10-4 L
COMPAD00485
36
2
SWIVEL ELBOW 10mm MSE 10-4 L
COMPAD00505
37
1
TWIN PORT SANDWICH BLOCK (INSIDE)
GA9178A
38
2
SANDWICH BLOCK INNER O-RING
ORINGS00180
39
1
SANDWICH BLOCK OUTER O-RING
0RINGS01025
40
1
TWIN PORT SANDWICH BLOCK (OUTSIDE)
GA9178B
41
2
1/4" LUCIFER OIL SOLENOID VALVE
SOLOIL00260
42
2
STANDPIPE ADAPTOR 10mm MSA 10-4 L
COMPAD00535
43
1
1/4" BSP OIL MANIFOLD BLOCK 4 PORT
GA13237
44
1
1/4" MINI BALL VALVE
VALOIL00110
45
1
M5 COPPER WASHER
COPWAS00025
46
2
0 - 600 PSI PRESSURE GUAGE
PRESGA00100
47
2
MALE STUD COUPLING 10mm x 1/2" MMC 10-8 L
COMPAD00495
48
6
1/2"BSP DOWTY 'BONDED' SEAL
SEADOW00110
49
1
1/2" LUCIFER OIL SOLENOID VALVE
SOLOIL00240
50
2
MALE STUD COUPLING 10mm X 3/8" MMC 10-6 L
COMPAD00490
51
2
3/8"BSP DOWTY 'BONDED' SEAL
SEADOW00100
52
1
POSITIONAL ELBOW 3/4" x 1/2"
CONELB00125
53
1
DH1-1-CLOCKWISE ROTATION
DH1-2-CLOCKWISE ROTATION
DH1-1-ANTI-CLOCKWISE ROTATION
DH1-1-ANTI-CLOCKWISE
PUMDUN01012
PUMDUN01010
PUMDUN01025
PUMDUN01020
54
1
COPPER WASHER 1/2"
COPWAS00110
55
1
COPPER WASHER 3/8"
COPWAS00100
56
1
MANIFOLD No. 4 WITH VALVE CLUSTER
GA16780
57
1
1"BSP 'HEAVYWEIGHT' BARREL NIPPLE
PIPNIP01340
58
1
1/2" BSP YORKSHIRE FITTING
YORFIT00530
59
1
3/8" BSP BANJO BOLT #7 x 70
GA10382
60
1
1/2" BSP BANJO BOLT #4 x 72
GA10143
70
1
D.90 MOTOR BELL HOUSING
GA05900
