To change the time value:
● Press and to position the cursor.
● Press and to modify the value at the relevant position.
● Confirm your entries with OK.
Setting
Setting
Setting
Setting the
the
the
the time
time
time
time
Set the time T = 12:00 minutes:
1. Move the cursor to the first digit: Press or
2. Select the digit '1': Press or
3. Shift the cursor to the second digit: Press or
4. Select digit '2': Press or
5. Move the cursor to the unit: Press or
6. Select the timebase 'm' (for minutes): Press or
Showing/hiding
Showing/hiding
Showing/hiding
Showing/hiding parameters
parameters
parameters
parameters -
-
-
- the
the
the
the parameter
parameter
parameter
parameter protection
protection
protection
protection mode
mode
mode
mode
If you want to show/hide the parameter and allow/prevent its modification in parameter
assignment mode:
1. Move the cursor to the protection mode: Press or
2. Select the protection mode: Press or
The display should now show:
3. Confirm your entries with: OK
Enabling/disabling
Enabling/disabling
Enabling/disabling
Enabling/disabling retentivity
retentivity
retentivity
retentivity
To decide whether you want to retain your current data after a power failure or not:
1. Move the cursor to the retentivity setting: Press or
2. Select the retentivity setting: Press or
The display now shows:
