3. Confirm your entries with OK
Note
For further information on the protection mode, refer to the topic "Parameter protection ".
For further information on retentivity, refer to the topic "Retentivity ".
You can modify the protection mode and retentivity setting only in programming mode.
This is not possible in parameter assignment mode.
In this manual, the protection mode ("+" or "-") and retentivity ("R" or "/") settings are only
shown in the displays where these can actually be changed.
Verification
Verification
Verification
Verification of
of
of
of the
the
the
the circuit
circuit
circuit
circuit program
program
program
program
This program branch for Q1 is now completed. xLogic shows you the output Q1. You can once
again view the circuit program on the display. Use the keys to browse the circuit program; that
is, press or to move from block to block, and to move between the inputs at a block.
Closing
Closing
Closing
Closing the
the
the
the programming
programming
programming
programming mode
mode
mode
mode
Although you were shown how to exit the programming mode when you created your first
circuit program, here is a reminder:
1. Return to the programming menu: Press ESC
2. Return to the main menu: Press ESC
3. Move the '>' cursor to 'Start': Press or
4. Confirm 'Start': Press OK
xLogic is back in RUN mode:
3.
3.
3.
3. 6
6
6
6 .
.
.
. 7
7
7
7 Deleting
Deleting
Deleting
Deleting a
a
a
a block
block
block
block
Let us assume you want to delete the connection of block B2 from your circuit program and
connect B1 directly to Q1.
