Eaton 93PR Series User And Installation Guide

25-75 kW
User's and Installation Guide 23
The UPS equipment operating environment must meet the weight requirements shown in Table in Table 3-1:
Dimensions and 3-2: 93PR 25-75kW UPS.
Table 3-1: Dimensions
UPS 25-75kW
Shipping dimensions (WxDxH) 900x1300x2200 mm
Cabinet dimensions (WxDxH) 600x1100x2020 mm
UPM
Shipping dimensions (WxDxH) 790*590*270mm
UPM dimensions (WxDxH) 439*595*130mm
BATTERY MODULE
Shipping dimensions (WxDxH) 227x1114x277 mm
UPM dimensions (WxDxH) 107x900x156 mm
Table3-2:UPScabinetweights
UPS
25-75kW
Without Internal Battery Version
25-75kW
With Internal Battery Version
Shipping weight 375 kg 449 kg
Installed weight 265 kg 339 kg
UPM
Shipping weight 31.5 kg
Installed weight 27.5 kg
BATTERY MODULE
Shipping weight 33 kg
Installed weight 31 kg
25-75kW
Without Internal Battery Version+
UPM*3
25-75kW
With Internal Battery Version +
UPM*3 + Battery Module*20
Installed weight 347.5 kg 1041.5 kg
Floor loading 800 kg/m
2
2000 kg/m
2

Eaton 93PR Series Specifications

General

Series	93PR
Frequency	50/60 Hz
Topology	Double Conversion Online
Operating Temperature	0 to 40 °C (32 to 104 °F)
Humidity	0 to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Type	UPS
Input Voltage	380/400/415 V (3-phase + N + PE)
Output Voltage	380/400/415 V (3-phase + N + PE)
Battery Type	Valve-Regulated Lead-Acid (VRLA)
Communication Interface	RS-232, USB, Ethernet, Modbus, SNMP
Form Factor	Tower
