Eaton 93PR Series - Figure 3-4. Remove All Fixed Shipping Brackets and Screw Fixed on the Pallet; Figure 3-5. Attaching the Ramp to the Pallet; Figure 3-6. Rolling the Cabinet down the Ramp

25-75 kW
User's and Installation Guide 33
Ramp (side panel
from wood container)
Figure3-4:RemoveallFixedShippingBracketsandScrewFixedonthePallet
Front Shipping Bracket
Leveling Feet
Leveling Feet
Leveling Feet
Leveling Feet
Front Door
UPS Cabinet
Pallet
Rear Shipping
Bracket
Right Shipping Bracket
Left Shipping Bracket
Figure 3-5: Attaching the Ramp to the Pallet Figure3-6:RollingtheCabinetDowntheRamp
