Eaton 93PR Series - Instruction for Removing the Battery Module Packaging; Figure 3-8. Instruction for Femoving the Battery Module Packaging

25-75 kW
User's and Installation Guide 35
3.5 Instruction for Removing the Battery Module Packaging
1. Cut off the packing strap and open the carton (see Figure 3-8);
2. Lift the foam on the Battery module upward to remove them (see Figure 3-8);
3. Take out the Battery module (see Figure 3-8).
NOTE
Heavyunit.Itmustbecarriedbytwopeopleatthesametimetoavoidinjury.
NOTE
CheckwhethertheUPSisdamagedduringtheprocessoftransportationornot.Shouldanydamagebeobserved
orpartsbefoundmissing,donotstartthemachine.Contacttheforwarderanddistributorimmediately.
WARNING
ELECTRIC SHOCK!
Onlyprofessionalsbeallowedtoremovethebatteryterminalcoversbeforeinstallation.
Figure 3-8: Instruction for Femoving the Battery Module Packaging
battery terminal cover
