Eaton 93PR Series - Figure 4-9. Pimplified CAN and Pull-Chain Wiring for Parallel UPP System; Figure 4-10. CAN and Pull-Chain Wiring for Parallel UPP with Mobs

25-75 kW
User's and Installation Guide 48
Figure 4-10: CAN and Pull-Chain Wiring for Parallel UPP With MOBs
10
9
10
9
10
9
11
12
11
12
11
12
Figure 4-9: Pimplified CAN and Pull-Chain Wiring for Parallel UPP System
NOTE
Thisdrawingisfordistributedbypasswiringpurposesandisnotafloorlayoutplan.UPPscanbeplacedinany
physical order.
NOTE
ExternalCANconnectionsbetweenUPPsrequireshieldedtwistedpairwire.
NOTE
UsetwistedpairwiringbetweentheUPPandMOBAUXcontacts.
