25-75 kW
User's and Installation Guide
56
Figure6-1:UPSSwitchPosition
Input switch
Output switch
Maintenance bypass switch
Input switch
Output switch
Maintenance bypass switch
With Internal Battery Version
Without Internal Battery Version
Battery switch
Neutral switch
Neutral switch
