6.10 STS Module
The STS module mainly supports the static bypass function, which includes SCR and SCR input
contactors, and cooling fan.
Support hot swap.
NOTE
CannotdisconnectandremovetheSTSmodulewhiletheUPSisinBypassMode.
NOTE
STS module all repairs and service should be performed by AUTHORISED SERVICE PERSONNEL ONLY.
Figure 6-13: STS Module
