6 Implemented EtherNet/IP objects
6.1 Standard CIP object classes
SmartWire-DT Gateway EU5C-SWD-EIP-MODTCP 08/17 MN120003Z EN www.eaton.com 59
6.1.3 Assembly object 0x4
The assembly object is used to group input or output data in order to be able
to easily read and write large volumes of data using a single connection. The
output data to all SmartWire-DT modules is grouped in instance 100. The
inputs of all SmartWire-DT modules are grouped in instance 101. The object
length varies and depends on the number of SmartWire-DT modules and
their data volumes. The maximum object length is 496 bytes for each
instance.
Overview of functions
Class Attributes
Common Services
Table 10: Common Services
Classes/
Instances
Attribute/Services &Value
Classes
Attributes 0x01, 0x02, 0x03, 0x04, 0x06, 0x07
Services 0x0E
Instances
Attributes 0x03, 0x04
Services 0x10 (for instance 100 only), 0x0E
For explanations regarding the services, see Tabelle 6
Attribute number Attribute Name Get/Set Data type Description &Value
1 (0x01) REVISION G UINT Class version 0x00 02
2 (0x02) MAX CLASS ID G UINT Highest supported class number 0x00 65
3 (0x03) NUMBER OF INSTANCES G UINT Number of instances 0x00 02
4 (0x04) OPTIONAL ATTRIBUTE LIST
NUMBER OF Attributs
OPTIONAL Attributs
G STRUCT of
UNIT
ARRAY of UNIT
Number of attributes
List of optional attributes
0x00 01
0x00 04
6 (0x06) MAX CLASS IDENTIFIER G UINT Highest number of the implemented
class attribute
0x00 07
7 (0x07) MAX INSTANCE ATTRIBUTE G UINT Highest number of the implemented
instance attribute
0x00 04
Service code Class Instance
100
Instance
101
Service name
14 (0x0E) yes yes yes Get_Attribute_Single
Returns the specific attribute's content
16 (0x10) No yes No Set_Attribute_Single
Modifies a single attribute.
