6 Implemented EtherNet/IP objects
6.2 Manufacturer-specific object classes
SmartWire-DT Gateway EU5C-SWD-EIP-MODTCP 08/17 MN120003Z EN www.eaton.com 63
6.2 Manufacturer-specific object classes
In addition to standard object classes, there are also vendor-specific classes
(VSC = Vendor-Specific Class) that make it possible to access individual prop-
erties corresponding to the EtherNet/IP gatewayand the SmartWire-DT mod-
ules. Object classes 0x64 and 0x65 are used for this purpose.
6.2.1 Gateway object 0x64
Gateway object 0x64 makes it possible to access the data corresponding to
the EU5C-SWD-EIP-MODTCP gateway and the SmartWire-DT system. In
addition, acyclic access to the SmartWire-DT modules' data is also available.
Overview of functions
Class attributes of gateway object
Table 13: Class attributes of gateway object 0x64
Class Property Name Description
100 (0x64) Gateway Data corresponding to gateway EU5C-SWD-EIP-MODTCP and the
SmartWire-DT system, as well as acyclic access to the Smart-
Wire-DT modules
101 (0x65) SmartWire-DT The SmartWire-DT modules' data and settings
Classes/
Instances
Attribute/Services &Value
Classes
Attributes 0x64, 0x65, 0x66, 0x67
Services 0x0E
Instances
Attributes 0x64, x65, 0x66, 0x67, 0x68, 0x69, 0x6A, 0x6B, 0x6C, 0x6D, 0x6E, 0x6F,
0x70, 0x71, 0x72,0x73, 0x74
Services 0x10, 0x0E
For explanations regarding the services, see Tabelle 6
Attribute number Attribute Name Get/Set Data type Description &Value
100 (0x64) CLASS REVISION G UINT Version 0x00 01
101 (0x65) MAX OBJECT INSTANCE G UINT Maximum number of object instances 0x00 01
102 (0x66) NUMBER OF INSTANCES G UINT maximum number of instances 0x00 01
103 (0x67) MAX CLASS IDENTIFIER G UINT Highest number of the implemented
class attribute
0x00 67
