6 Implemented EtherNet/IP objects
6.2 Manufacturer-specific object classes
64 SmartWire-DT Gateway EU5C-SWD-EIP-MODTCP 08/17 MN120003Z EN www.eaton.com
Instance attributes of gateway object
Table 14: Instance attributes of gateway object 0x64
Attribute number
Attribute Name Get/Set Data type Description &Value
100 (0x64) MAX OBJECT ATTRIBUTE G USINT Holds the number of the last object attri-
bute
0x74
101 (0x65)
STATE G UINT Current Gateway Status see ￫
Table 15,
page 66
103 (0x67) DEVICE ID G UINT Manufacturer ID
104 (0x68) ORDER NAME G SHORT STRING Length (first byte) and product name
("EU5C-SWD-EIP-MODTCP")
13 45 55 35
43 2D 53 57
44 2D 45 49
50 2D 4D 4F
44 54 43 50
105 (0x69) SERIAL NO. SHORT STRING Device serial number
106 (0x6A) SW REVISION SHORT STRING Firmware Version of the Gateway
107 (0x6B) PROJECT PARAMETER STRUCT of
UINT
USINT
USINT
UINT
Gateway Parameters
SWD Baud rate (in kBit/s)
Number of modules in the planned
SmartWire-DT configuration
CyclicExchangeDelay in ms
SmartWire-DT project parameters
„SmartWire-
DT device
parameters;
possible
values of
instance
attribute
107,
gateway
object
0x64“￫
Table 16,
page 66
108 (0x6C)
PRODUCED DATA SIZE G UINT Length of input data
109 (0x6D) CONSUMED DATA SIZE G UINT Lenght of output data
110 (0x6E) FIRST CONFIGURATION ERROR
(FIRST MISSING MANDATORY
MODULE)
G UINT First module with an error (invalid part
no., wrong serial number, etc.)
111 (0x6F) NODE COUNT G UINT Number of modules in the target config-
uration
112 (0x70) NODE IDENTS G
VENDOR
DEVICE
ARRAY of
STRUCT
USINT
USINT
Manufacturer and device IDs for all the
SmartWire-DT modules in the target
configuration
Manufacturer
Device identification:
113 (0x71) INDEX G/S USINT Object index for acyclic data
114 (0x72) DATA G/S ARRAY of
USINT
Data for reading / writing acyclic data
