6 Implemented EtherNet/IP objects
6.2 Manufacturer-specific object classes
68 SmartWire-DT Gateway EU5C-SWD-EIP-MODTCP 08/17 MN120003Z EN www.eaton.com
Acyclic read request example
Acyclic write operation example
SET attribute 113 (0x71h):
Object index for acyclic data
Entry specifying which object should be read
↓
GET attribute 114 (0x72h):
Read data
↓
GET attribute 115 (0x73h):
Length of received data
↓
GET attribute 116 (0x74h):
Read the request's error status
SET attribute 113 (0x71h):
Object index for acyclic data
Entry specifying which object should be written to
↓
SET attribute 115 (0x73h):
Length of the byte array (1 - 120)
↓
SET attribute 114 (0x72h):
Write the data
↓
GET attribute 116 (0x74h):
Read the request's error status
