6 Implemented EtherNet/IP objects
6.2 Manufacturer-specific object classes
70 SmartWire-DT Gateway EU5C-SWD-EIP-MODTCP 08/17 MN120003Z EN www.eaton.com
SmartWire-DT module device status
Table 19: Cyclic input data concerning the SmartWire-DT module's device status
106 (0x6A) SW REVISION G SHORT STRING Firmware Version
107 (0x6B) CURRENT PROFILE G UDWORD Data profile
108 (0x6C) CURRENT PARAMETER G USINT Mode parameter
109 (0x6D) EXTENDED DIAGNOSE G STRUCT of
UDWORD
UINT
ARRAY of USINT
Extended SmartWire-DT module
diagnostics
Time point
Extended diagnostic message
￫ Table 20, page 71
List of currently pending diag-
nostic messages (maximum of 5)
￫ Table 21, page 71
110 (0x6E) EXTENDED PARAMETER
SIZE
G USINT Size of extended parameter data
111 (0x6F) EXTENDED PARAMETER G ARRAY of USINT Extended parameter data
(0 - 120 bytes)
112 (0x70)
113 (0x71) INDEX G/S USINT Object index for cyclic data
114 (0x72) DATA G/S ARRAY of USINT Data buffer for acyclic read/write
data
115 (0x73) LENGTH G/S USINT Length of read/write data
116 (0x74) ERROR G UINT Error Message
117 (75h) PRODUCED DATA SIZE G UINT Size of SmartWire-DT module
input data
118 (76h) PRODUCED DATA G ARRAY of USINT Input data
119 (77h) CONSUMED DATA SIZE G UINT Size of SmartWire-DT module
output data
120 (78h) CONSUMED DATA G ARRAY of USINT Output data
BIT Name Value/Description
0 DIAG 0: no diagnostic alarm
1: SmartWire-DT module delivering diagnostics
1 RESERVED reserved
2 PRSNT 0: SmartWire-DT module not present (input data has a value
of 0)
1: module present
3 SUBST 0: Planned SmartWire-DT module present
1: Universal module present instead of planned SmartWire-
DT module
4 - 15 RESERVED reserved
Attribute
number
Attribute Name Get/Set Data type Description
