7 Modbus/TCP – SmartWire-DT implementation
7.5 Acyclic data communications
80 SmartWire-DT Gateway EU5C-SWD-EIP-MODTCP 08/17 MN120003Z EN www.eaton.com
BIT Name Description
4 DIAG 0: There are currently no diagnostic messages from the module.
1: There is at least one diagnostic message. The exact cause of the diagnostic
message can be read by using acyclic services.
"SmartWire-DT Modules IP20", MN05006001Z, describes the various possible diag-
nostic alarms for each SmartWire-DT module.
6 PRSNT 0: Communications cannot be established between the gateway (SmartWire-DT coor-
dinator) and the SmartWire-DT module.
All input data has a value of 0.
1: The SmartWire-DT module is present and is exchanging data with the gateway
(SmartWire-DT coordinator).
7 SUBST 0: The planned SmartWire-DT module is present
1: An M22-NOP(C) universal module is present instead of the planned SmartWire-DT
module
