Eaton MMX11 Series User Manual

Appendix
04/10 MN04020001Z-EN
174
Block Transformatoren-Elektronik GmbH & Co. KG
Postfach 11 70
27261 Verden
Max-Planck-Straße 36 - 46
Telefon: (0 42 31) 6 78-0
Telefax: (0 42 31) 6 78-1 77
E-Mail: info@block-trafo.de
Internet: www.block-trafo.de
DF51- Maximum
output voltage
Rated
operational
current
(motor
current)
I
e
[A]
Assigned
sine-wave
filter
320-4K0 3 ~ 240 V + 10 % 17.5 SFB 400/16.5
1)
(SFB 400/23.5)
320-5K5 24 SFB 400/23.5
320-7K5 32 SFB 400/32
322-025 1.6 SFB400/4
322-037
2.6
322-055
3
322-075 4
322-1K1 5 SFB400/10
322-1K5 8
322-2K2 11 SFB400/10
1)
(SFB 400/16.5)
340-037 3 ~ 480 V + 10 % 1.5 SFB400/4
340-075 2.5
340-1K5 3.5
340-2K2 5.5 SFB400/10
340-3K0 7.8
340-4K0 8.6
340-5K0
13 SFB400/16.5
340-7K5 16
1) At continuous 100 % motor load, use a sinusoidal filter of the next
higher (current) rating here.
Protection type
IP00, suitable for flush mounting in
devices and systems
Typical voltage drop 3 x 30 V
Frequency range
0 - 120 Hz
Permissible pulse frequency
3 - 8 kHz, fixed
Ambient temperature
F 40 °C
Approvals
c-UL-US
h
For more technical data for the SFB400/… series
sine-wave filters, see the manufacturer’s instructions.
