Eaton MMX11 Series User Manual

04/10 MN04020001Z-EN
Sinusoidal filters
175
Frequency inverters Assigned sinusoidal filter
U
LN
maximum 3 AC 0 - 480 V +10 % (0 - 120 Hz)
Type Rated
operational
current
Type Article no.
[Moeller]
Maximum permissible
rated operational
current
I
e
[A]
I
N
[A]
MMX11AA1D7… 1.7 SFB 400/4 271538 4
MMX11AA2D4… 2.4
MMX11AA2D8… 2.8
MMX11AA3D7… 3.7
MMX12AA1D7… 1.7
MMX12AA2D4… 2.4
MMX12AA2D8… 2.8
MMX12AA3D7… 3.7
MMX32AA1D7… 1.7
MMX32AA2D4… 2.4
MMX32AA2D8… 2.8
MMX32AA3D7… 3.7
MMX34AA1D3… 1.3
MMX34AA1D9… 1.9
MMX34AA2D4… 2.4
MMX34AA3D3… 3.3
MMX11AA4D8… 4.8 SFB 400/10 271590 10
MMX12AA4D8… 4.8
MMX12AA7D0… 7
MMX12AA9D6… 9.6
MMX32AA4D8… 4.8
MMX32AA7D0… 7
MMX34AA4D3… 4.3
MMX34AA5D6… 5.6
MMX34AA7D6… 7.6
MMX34AA9D0… 9
MMX32AA011… 11 SFB 400/16.5 271591 16.5
MMX34AA012… 12
MMX34AA014… 14
1)
1) Reduced rated operational data: Ambient temperature maximum +40 °C, maximum pulse frequency: 4 kHz, side mounting space (left and right)
>10 mm.
