ECKELMANN UA 412 S - Main Menu; Menu 1 Actual Values

KGL Operating Manual – UA 412 S 2019-01-14 /100 122
9.2.1 Main menu
KÜHLSTELLE POS: XXXXX
1 Actual values Continue to menu 1
2 Setpoints Continue to menu 2
3 Clock Continue to menu 3
4 Messages Continue to menu 4
5 Archive Continue to menu 5
6 Configuration Continue to menu 6
9.2.2 Menu 1 Actual values
ISTWERTE POS: XXXXX
1 Temperature sensor Continue to menu 1-1
2 Cooling Continue to menu 1-2
3 Defrost Continue to menu 1-3
4 Not applicable for this controller type
5 Alarm Continue to menu 1-5
6 Frame heater Continue to menu 1-6
Menu 1-1 Temperature sensor
TEMPERATUR Pos: XXXXX
Temperat. R2 xxx °C Display current supply air temperature terminals Z11/Z12
Temperat. R4 xxx °C Display current return air temperature terminals Z21/Z22
Temperat. R1.1 xxx °C Display current evaporator / defrost end temperature terminals Z31 / Z32
Temperat. R3 xxx °C Display current temperature HACCP terminals Z41 / Z42
Temperat. R1.2 xxx °C Display current evaporator / defrost end temperature terminals Z51 / Z52
Temperat. S7.1 xxx °C Display current cylinder end temperature compressor 1 terminals Z61/ Z62
Temperat. S7.2 xxx °C Display current cylinder end temperature compressor 2 terminals Z71/ Z72
Temperat. S7.3 xxx °C Display current cylinder end temperature compressor 3 terminals Z81/ Z82
Temperat. S7.4 xxx °C Display current cylinder end temperature compressor 4 terminals Z91/ Z92
Temperat. S8 xxx °C Display current brine outlet temperature terminals Z01/Z02
po xxxb Display current pressure po
to xxx °C Display current temperature to
pc xxxb Display current pressure pc
tc xxx °C Display current temperature tc
Menu 1-2 Cooling
KÜHLUNG 1 Pos: XXXXX
Kühlung xxx Display current ON / OFF state of the cooling
Temperat. R2 xxx °C Display current supply air temperature terminals Z11/Z12
Setpoint R2 xxx °C Display setpoint supply air temperature for comparison
Hysteresis R2 xxx K Display setpoint hysteresis supply air temperature
Temperat. R4 xxx °C Display current return air temperature terminals Z21/Z22
Setpoint R4 xxx °C Display setpoint return air temperature for comparison
