Submenu Submenu 2 Menu number Menu name
acknowledge 4-2
delete 4-3 MESSAGES
Archive 5 ARCHIVE
Configuration 6 KONFIGURAT
Refrigeration point 6-1 REFRIGERATION POINT
Controller 6-2 CONTROLLER
Type and version 6-2-1 VERSION
Temperature display 6-2-2 DISPLAY
Alarm delay 6-2-3 ALARMVERZ.
230 V inputs 6-2-4 230V EING.
Sensor type 6-2-5 SENSOR TYPE
Analogue inputs 6-2-6 ANALOGUE INPUTS
Verfl.-Satz 6-2-7 V.-SATZ
Cooling 6-3 COOLING
Language 6-4 LANGUAGE
Alarm priorities 6-5 ALARMPRIOS
Emergency power operation 6-6 NOTNETZ
9.1.1 Main menu
KÜHLSTELLE POS: XXXXX
1 Actual values Continue to menu 1
2 Setpoints Continue to menu 2
3 Clock Continue to menu 3
4 Messages Continue to menu 4
5 Archive Continue to menu 5
6 Configuration Continue to menu 6
9.1.2 Menu 1 Actual values
ISTWERTE POS: XXXXX
1 Temperature sensor Continue to menu 1-1
2 Cooling Continue to menu 1-2
3 Defrost Continue to menu 1-3
4 Not applicable for this controller type
5 Alarm Continue to menu 1-5
6 Frame heater Continue to menu 1-6
Menu 1-1 Temperature sensor
TEMPERATUR Pos: XXXXX
Temperat. R2 xxx °C Display current supply air temperature terminals Z11/Z12
Temperat. R4 xxx °C Display current return air temperature terminals Z21/Z22
Temperat. R1 xxx °C Display current evaporator / defrost end temperature terminals Z31 / Z32
Temperat. R3 xxx °C Display current temperature HACCP terminals Z41 / Z42
Temperat. R6 xxx °C Display current evaporator output temperature terminals Z51 / Z52
