1 Conventions
1.1 Explanation of 'Safety Instructions and Hazard Warnings'
Safety instructions or hazard warnings are composed of four elements:
The pictogram and the text at the side pf the page.
A short, concise description of the danger.
A description of the possible consequences.
A catalogue with measures for avoidance.
For example:
Warning about dangerous electrical voltage! Danger of electric shock! BEFORE connecting and
disconnecting, it must be checked that at the 230 V AC relay outputs!no voltage is present
1.2 Explanation of 'General Note'
A general note consists of two elements:
The pictogram and the "Info" text at the side pf the page, and
the actual note text:
For example:
Further information for the protection rating of the device is contained in the chapter Technical Data
.UA 412 S, page 119
1.3 Warning Signs and Symbols Used
Explanation of the warning signs and symbols used for the safety instructions and hazard warnings in this
documentation:
Attention symbol - general hazard warning
1. Hazard warning
The attention symbol indicates all safety instructions in this operating and service manual that result
in danger to life and limb of persons if not observed. Carefully comply with the work safety
instructions and proceed with particular caution in these cases.
2. Attention
The attention symbol highlights guidelines, regulations, instructions and correct working procedures
that must particularly be observed in order to prevent damage to and destruction of E*LDS
components or any malfunction (for example to prevent damage to goods).
Failure to observe the attention symbol can result in personal injury (in extreme cases serious injuries or
death) and/or damage to property!
