6 UA 412 S installation and start-up
Important safety instructions! Before the installation and commissioning of the controller, the chapter
must be carefully read in its entirety and all safety instructions and hazard Conventions, page 7
warnings observed.
The controller should only be used with compatible versions of the LDSWin PC software, otherwise
the scope of functions can be restricted. : The latest LDSWin version should always be used.Tip
6.1 Installation
The case controller is available in the UA 412 S / UA 413 S versions.
UA 412 S - complete
design
Further details about the distinguishing features of the controller types are explained in chapter Controller types
. , page 16
6.1.1 Case controller for DIN rail mounting
The power loss of the device is approx. 11 VA and must be taken into account for the installation.
