KÜHLUNG 1 Pos: XXXXX
Hysteresis R4 xxx K Display setpoint hysteresis return air temperature
Compressor Display current OFF / ON state of the enable of all compressors terminals 35/36/38
Verd.Drehzahl 0% Speed of the compressor
Compressor 1 Display current OFF / ON state of the compressor 1 terminals 25/26/28
Compressor 2 Display current OFF / ON state of the compressor 2 terminals 53/54
Compressor 3 Display current OFF / ON state of the compressor 3 terminals 63/64
Compressor 4 Display current OFF / ON state of the compressor 4 terminals 43/44
Dauerl.überw. OFF Display current ON / OFF state of the continuous monitoring
Status Licht AUS Display current ON / OFF state of the case lighting terminals 81/82
Menu 1-3 Defrost
ABTAUUNG 1 Pos: XXXXX
Counting rate X Display counting rate
Defrost counter X Display defrost counter
Abtauung XXX Display current ON / OFF state of the defrost
Temperat. R1.1 XXX °C Display current evaporator defrost end temperature terminals Z31 / Z32
Temperat. R1.2 XXX °C Display current evaporator defrost end temperature terminals Z51 / Z52
Abtauendtemp XXX °C Display setpoint defrost end temperature for comparison
Wartezeit XX m Display setpoint wait time
Abtropfzeit XX m Display setpoint drip time
letzte Abt. XX hh:mm Display time (date, time) of the last started defrost
Menu 1-4
Not applicable for this controller type.
Menu 1-5 Alarm
ALARM Pos: XXXXX
Alarm relay XXX Display current ON / OFF state of the output alarm terminals 15/16/18
Sicherheitsk. Display current ON / OFF state of the input terminals D41/D42
Soll Übertemp1 XX °C Display setpoint overtemperature
Soll Untertmp1 XX K Display setpoint low temperature
Menu 1-6 Frame heater
RAHMEN XXXXX
Frame heater xxx Display current ON / OFF state of the frame heater output terminals 91/92
Einschaltdauer xxx % Display current run time of the frame heater
Feuchte XXX% Display current room humidity (transmitted via CAN nus from the VS using the installed humidity sensor)
Raum-Temp xx °C Display current room temperature (transmitted via CAN nus from the VS using the installed room temperature sensor)
9.2.3 Menu 2 Setpoints
SOLLWERTE POS: XXXXX
1 Cooling Continue to menu 2-1
2 Defrost Continue to menu 2-2
