RAHMEN XXXXX
Frame heater xxx Display current ON / OFF state of the frame heater output terminals 91/92
Einschaltdauer xxx % Display current run time of the frame heater
Feuchte XXX% Display current room humidity (transmitted via CAN nus from the VS using the installed humidity sensor)
Raum-Temp xx °C Display current room temperature (transmitted via CAN nus from the VS using the installed room temperature sensor)
9.1.3 Menu 2 Setpoints
SOLLWERTE POS: XXXXX
1 Cooling Continue to menu 2-1
2 Defrost Continue to menu 2-2
3 Not applicable for this controller type
4 Alarm Continue to menu 2-4
5 Frame heater Continue to menu 2-5
Menu 2-1 Cooling
KÜHLUNG POS: XXXXX
1 Setpoints Continue to menu 2-1-1
2 Sollwerte Umsch. Continue to menu 2-1-2
is not displayed when toggle setpoint is deactivated (menu 3-3)
Menu 2-1-1 Setpoints
KÜHLUNG POS: XXXXX Input Default
Setpoint R2 xxx °C Setpoint supply air temperature -10..20 -2 °C
Hysteresis R2 X K Setpoint hysteresis supply air temperature 1..8 4 K
Setpoint R4 XXX °C Setpoint return air temperature -10..20 6 °C
Hysteresis R4 X K Setpoint hysteresis return air temperature 1..8 2 K
Menu 2-1-2 Sollwerte Umsch.
KÜHLUNG POS: XXXXX Input Default
Setpoint R2 xxx °C Setpoint supply air temperature -10..20 -4 °C
Hysteresis R2 X K Setpoint hysteresis supply air temperature 1..8 4 K
Setpoint R4 xxx °C Setpoint return air temperature -10..20 5 °C
Hysteresis R4 X K Setpoint hysteresis return air temperature 1..8 4 K
Menu 2-2 Defrost
ABTAUUNG POS: XXXXX Input
1 Setpoints Continue to menu 2-2-1 1
2 Sollwerte Umsch. Continue to menu 2-2-2
is only displayed if two-zone operation is set (menu 6-1)
2
Menu 2-1-1 Setpoints
ABTAUUNG POS: XXXXX Input Default
Abtauendtemp XX °C Setpoint defrost end temperature --, 0..20 10 °C
