For voltage testing, each terminal connection has openings for probe tips of multimeters (V) that are
designed with protection against direct contact:
Risk of damage! All mating connectors be guided vertically and attached / must always
disconnected without twisting so that the pins on the main board are not bent and damaged.
6.2 Basic settings
Settings BEFORE the connection of the power supply
Decade switches S1 and S2:
- Setting of the CAN bus address (node number) 1..99, see chapter Setting the CAN bus address, page
44
DIP switch S3:
