KGL Operating Manual – UA 412 S 2019-01-14 /88 122
TEMPERATUR Pos: XXXXX
Temperat. S7 xxx °C Display current cylinder end temperature compressor 1 Z61/ Z62
Kondens.Temp. xxx °C Display current condensation temperature terminals Z71/Z72
Sole Eintritt xxx °C Display current brine inlet temperature terminals Z81/Z82
Temperat. S8 xxx °C Display current brine outlet temperature terminals Z91/Z92
po xxxb Display current pressure po
to xxx °C Display current temperature to
pc xxxb Display current pressure pc
tc xxx °C Display current temperature tc
Menu 1-2 Cooling
KÜHLUNG 1 Pos: XXXXX
Kühlung xxx Display current ON / OFF state of the cooling
Temperat. R2 xxx °C Display current supply air temperature terminals Z11/Z12
Setpoint R2 xxx °C Display setpoint supply air temperature for comparison
Hysteresis R2 xxx K Display setpoint hysteresis supply air temperature
Temperat. R4 xxx °C Display current return air temperature terminals Z21/Z22
Setpoint R4 xxx °C Display setpoint return air temperature for comparison
Hysteresis R4 xxx K Display setpoint hysteresis return air temperature
Verd.Drehzahl 0% Speed of the compressor
Verfl.Lüfter AUS Display current ON / OFF state of the condenser fan
Dauerl.überw. AUS Display current ON / OFF state of the continuous monitoring
Status Licht AUS Display current ON / OFF state of the case lighting terminals 81/82
Menu 1-3 Defrost
ABTAUUNG 1 Pos: XXXXX
Abtauung XXX Display current ON / OFF state of the defrost
Abtaurelais 1 XXX Display current ON / OFF state of the defrost relay
Temperat. R1.1 XXX °C Display current evaporator defrost end temperature terminals Z31 / Z32
Abtauendtemp XXX °C Display setpoint defrost end temperature for comparison
Wartezeit XX m Display setpoint wait time
Abtropfzeit XX m Display setpoint drip time
letzte Abt. XX hh:mm Display time (date, time) of the last started defrost
Menu 1-4
Not applicable for this controller type.
Menu 1-5 Alarm
ALARM Pos: XXXXX
Alarm relay XXX Display current ON / OFF state of the output alarm terminals 15/16/18
Sicherheitsk. Display current ON / OFF state of the input terminals D41/D42
Soll Übertemp1 XX °C Display setpoint overtemperature
Soll Untertmp1 XX K Display setpoint low temperature
Menu 1-6 Frame heater
