4. Exit from the menu by tapping the button once and select menu 1 Refrigeration point ESC 6 Configuration -
.2 Controller
6 Configuration - 2 Controller
REGLERPOS: XXX
1 Type and version Type, serial number and Master / Slave (ON/OFF)
2 Temperature display Adjustment of the displayed temperature value
3 Alarm delay Input of an alarm delay time
4 230 V inputs 230 V inputs
5 Sensor type Selection of the temperature sensor of the type L243, K277 or 5K3A1
5. Select menu - .6 Configuration - 2 Controller 3 Alarm delay
6 Configuration – 2 Controller – 3 Alarm delay.
ALARMVERZ.POS: XXX
Fühlerbruch XXm Alarm delay for sensor fault
Über/Unter Tmp XXXm Alarm delay for high temperature or low temperature
keine Abtauung XXXh Alarm is tripped if no defrost is performed within this configurable time.
Selbsthaltung N NO: Automatic reset of non-transient alarms
YES: Alarms must be reset manually
Exit the menu by tapping the button once.ESC
6. Exit the menu by tapping the button twice and select Configuration ESC 3 Clock – 2 Defrost timer
Input of the relevant parameters in the following screen.
3 Clock - 2 Defrost Timer
ABTAUUHRPOS: XXX
Defrost timer INT Selection of defrost using external or internal defrost timer
Sicherheitsz. 60 min Safe defrost time; the defrost is not longer than this time.
Defrost 1 DD-DD hh:mm Entry of defrost times
Defrost 2 DD-DD hh:mm
...
Defrost 14 DD-DD hh:mm
man. AbtauungAUS Manual defrost ON/OFF
8. Exit from the menu by tapping the button.2 Defrost Timer ESC
9. Select menu , input of the relevant parameters in the following screen:3 Toggle Setpoint
3 Clock - 3 Toggle Setpoint
UMSCHALTNGPOS: XXX
Status AUS Only visible if Sollumschaltg. is set to INT or EXT
