Menu 6-2 - Controller
REGLER POS: XXXXX
1 Type and version Continue to menu 6-2-1
2 Temperature display Continue to menu 6-2-2
3 Alarm delay Continue to menu 6-2-3
4 230 V inputs Continue to menu 6-2-4
5 Sensor type Continue to menu 6-2-5
6 Analogue inputs Continue to menu 6-2-6
7 Verfl.-Satz Continue to menu 6-2-7
Menu 6-2-1 Type and version
VERSION POS: XXXXX Input Default
Controller type XXXXXXX Controller type that is set using the DIP switch S3 – SPIR410
Software Vers.: XXXX Software version of the case controller – x.yy
Serial No.: XXXXXX Serial number of the case controller –
Master/Sl. Mode XXX Synchronised defrost in the master / slave mode (ON/OFF) –
Menu 6-2-2 Temperature display
ANZEIGE POS: XXXXX Input Default
Offset XX K Offset for the display of the temperature -10..10 0K
Alarm symbol X Display of the alarm sysmbol in the temperature display of the BT30
, , (Y, N)
N
Menu 6-2-3 Alarm delay
ALARMVERZ. POS: XXXXX Input Default
Sensor fault XX m Alarm delay for sensor fault 0..30 15 min
Über/Unter Tmp XX m Alarm delay for overtemperature / low temperature 0..120 60 min
No Defrost XX h Alarm delay for no defrost --, 2..168 24 h
Selfholding X NO: Automatic reset of non-transient alarms.
YES: Alarms must be reset manually.
, , (Y/N)
N
Menu 6-2-4 230 V inputs
230V EING. POS: XXXXX Input Default
Input 1: XXXXXXXXXX Function of the digital input 1 terminals D11/D12 - DEFROST TIMER
Input 2: XXXXXXXXXX Function of the digital input 2 terminals D21/D22 - SOLLW.UMSCH
Input 3: XXXXXXXXXX Function of the digital input 3 terminals D31/D32 - MANUAL OFF
Input 4: XXXXXXXXXX Function of the digital input 4 terminals D41/D42 - SICH.KETTE
Menu 6-2-5 Sensor type
Only the first sensors 1..5 (Z11/12..Z51/52) can be configured here - the sensors 6..10 (Z61/62..Z01
/Z02) are only for Pt1000.
