10 Menu 2-10 - Log
Usingthisbutton,theentriesfortheinstallationstoredwiththeLDSWinPCsoftware(e.g.last
service, cleaning, refrigerant etc.) are displayed.
3 Menu 3 - 24h List, page 97
Display of the 24h list. All temperature sensors without exception of the case controllers (E*LDS
products and integrated external controllers) located in the E*LDS system are listed here together with their
hourly temperature average value. All case controllers can be considered within one day by tapping the up/
down buttons. Tapping on a row shows a graphical display of the day. Individual days can be changed between
by tapping the left/right buttons.
The screen contains the following parameters:
24 h list
Date Date of the 24h list
Position Position designation of the case controller
Sensor Designation of the temperature sensor
8 hours time range Columns of the displayed 8 hours time range with status indication
The following times are displayed in detail in the columns:
00:00 to 07:00, 08:00 to 15:00 or 16:00 to 23:00
The 24h display is divided into three time ranges of 8 hours each that can be displayed alternating between
0:00 to 7:00, 8:00 to 15:00 and 16:00 to 23:00 using the buttons on the bottom left edge of the screen. The 8:00
to 15:00 time range is the default while the other time ranges are zoomed out. Tap any of the corresponding
buttons to zoom in to the time range.
