11
Input IN2
12
Input IN3
13
Output OUT1
14
Output OUT2
4.
Plug the power supply cable (24VDC) into the control board (
Fig. 6 ,
9
).
5.
Connect the cable for the detergent empty signal to input IN1
10
.
6.
Connect the cable for the detergent pump control at the output OUT1
13
.
7.
Connect the cable for the rinse aid empty signal to input IN2
11
.
8.
Connect the cable for the rinse aid pump control at the output OUT2
14
.
If required, an optional conductive conductivity sensor (two-wire probe) or
a rinse temperature sensor can be connected to input IN3
12
.
9. Close the front flap.
CAUTION!
Assembly and connection
29 MAN054003, Ver. 1-02.2024
