Chapter 50
| IP Routing Commands
Open Shortest Path First (OSPFv2)
– 1020 –
configured as a backup connection that can take over if the normal connection
to the backbone fails.
â—† A virtual link can be configured between any two backbone routers that have
an interface to a common non-backbone area. The two routers joined by a
virtual link are treated as if they were connected by an unnumbered point-to-
point network.
â—† Any area disconnected from the backbone must include the transit area ID and
the router ID for a virtual link neighbor that is adjacent to the backbone.
Example
This example creates a virtual link using the defaults for all optional parameters.
Console(config-router)#network 10.4.0.0 0.255.255.0.0 area 10.4.0.0
Console(config-router)#area 10.4.0.0 virtual-link 10.4.3.254
Console(config-router)#
This example creates a virtual link using MD5 authentication.
Console(config-router)#network 10.4.0.0 0.255.255.0.0 area 10.4.0.0
Console(config-router)#area 10.4.0.0 virtual-link 10.4.3.254 message-digest-
key 5 md5 ld83jdpq
Console(config-router)#
Related Commands
show ip protocols ospf (1043)
network area This command defines an OSPF area and the interfaces that operate within this
area. Use the no form to disable OSPF for a specified interface.
Syntax
[no] network ip-address netmask area area-id
ip-address - Address of the interfaces to add to the area.
netmask - Network mask of the address range to add to the area.
area-id - Area to which the specified address or range is assigned. An OSPF
area identifies a group of routers that share common routing information.
The area ID can be in the form of an IPv4 address or as a four octet unsigned
integer ranging from 0-4294967295.
Command Mode
Router Configuration
Default Setting
Disabled
