Edge-Core ECS4620-28P - Page 617

Chapter 21 | VLAN Commands
Configuring Protocol-based VLANs
– 617 –
protocol-vlan
protocol-group
(Configuring Groups)
This command creates a protocol group, or adds specific protocols to a group. Use
the no form to remove a protocol group.
Syntax
protocol-vlan protocol-group group-id [{add | remove}
frame-type frame protocol-type protocol]
no protocol-vlan protocol-group group-id
group-id - Group identifier of this protocol group. (Range: 1-2147483647)
frame
15
- Frame type used by this protocol. (Options: ethernet, rfc_1042,
llc_other)
protocol - Protocol type. The only option for the llc_other frame type is
ipx_raw. The options for all other frames types include: arp, ip, ipv6, rarp.
Default Setting
No protocol groups are configured.
Command Mode
Global Configuration
Example
The following creates protocol group 1, and specifies Ethernet frames with IP and
ARP protocol types:
Console(config)#protocol-vlan protocol-group 1 add frame-type ethernet
protocol-type ip
Console(config)#protocol-vlan protocol-group 1 add frame-type ethernet
protocol-type arp
Console(config)#
protocol-vlan
protocol-group
(Configuring Interfaces)
This command maps a protocol group to a VLAN for the current interface. Use the
no form to remove the protocol mapping for this interface.
Syntax
protocol-vlan protocol-group group-id vlan vlan-id priority priority
no protocol-vlan protocol-group group-id vlan
group-id - Group identifier of this protocol group. (Range: 1-2147483647)
vlan-id - VLAN to which matching protocol traffic is forwarded.
(Range: 1-4094)
priority - The priority assigned to untagged ingress traffic.
(Range: 0-7, where 7 is the highest priority)
15. SNAP frame types are not supported by this switch due to hardware limitations.
