Chapter 24
| Multicast Filtering Commands
MLD Filtering and Throttling
– 722 –
Example
Console(config-mld-profile)#range ff01::0101 ff01::0202
Console(config-mld-profile)#
ipv6 mld filter
(Interface Configuration)
This command assigns an MLD filtering profile to an interface on the switch. Use
the no form to remove a profile from an interface.
Syntax
[no] ipv6 mld filter profile-number
profile-number - An MLD filter profile number. (Range: 1-4294967295)
Default Setting
None
Command Mode
Interface Configuration
Command Usage
â—† The MLD filtering profile must first be created with the ipv6 mld profile
command before being able to assign it to an interface.
â—† Only one profile can be assigned to an interface.
â—† A profile can also be assigned to a trunk interface. When ports are configured as
trunk members, the trunk uses the filtering profile assigned to the first port
member in the trunk.
Example
Console(config)#interface ethernet 1/1
Console(config-if)#ipv6 mld filter 19
Console(config-if)#
ipv6 mld max-groups This command configures the maximum number of MLD groups that an interface
can join. Use the no form to restore the default setting.
Syntax
ipv6 mld max-groups number
no ipv6 mld max-groups
number - The maximum number of multicast groups an interface can join at
the same time. (Range: 1-255)
Default Setting
255
