Chapter 24
| Multicast Filtering Commands
MVR for IPv6
– 750 –
mvr6
associated-profile
This command binds the MVR6 group addresses specified in a profile to an MVR6
domain. Use the no form of this command to remove the binding.
Syntax
[no] mvr6 domain domain-id associated-profile profile-name
domain-id - An independent multicast domain. (Range: 1-5)
profile-name - The name of a profile containing one or more MVR6 group
addresses. (Range: 1-21 characters)
Default Setting
Disabled
Command Mode
Global Configuration
Command Usage
MVR6 domains can be associated with more than one MVR6 profile. But since MVR6
domains cannot share the group range, an MVR6 profile can only be associated
with one MVR6 domain.
Example
The following an MVR6 group address profile to domain 1:
Console(config)#mvr6 domain 1 associated-profile rd
Console(config)#
clear mvr6 groups dynamic Clears multicast group information dynamically learned
through MVR6
PE
clear mvr6 statistics Clears the MVR6 statistics globally or on a per-interface basis PE
show mvr6 Shows information about MVR6 domain settings, including
MVR6 operational status, the multicast VLAN, the current
number of group addresses, and the upstream source IP
address
PE
show mvr6 associated-
profile
Shows the profiles bound the specified domain PE
show mvr6 interface Shows MVR6 settings for interfaces attached to the MVR6
VLAN
PE
show mvr6 members Shows information about the current number of entries in the
forwarding database, or detailed information about a specific
multicast address
PE
show mvr6 profile Shows all configured MVR6 profiles PE
show mvr6 statistics Shows MVR6 protocol statistics for the specified interface PE
Table 145: Multicast VLAN Registration for IPv6 Commands (Continued)
Command Function Mode
