Edirol PC-80 - Using PC-80 as MIDI Controller - Reset Message; Transmitting a Reset Message

76
Using the PC-80 as a MIDI controller keyboard
■ Transmits a Reset message
If you experience “stuck notes ” or other problems with the external MIDI sound module that’s
connected, you can transmit a Reset message to solve the problem.
This operation will transmit All Sound Off , All Notes Off , and Reset All Controllers messages
on all channels.
fig.panic-1_80
fig.util*
1
Simultaneously hold down the MIDI CH button and PGM CHANGE
button for a few moments.
The display will indicate “UTL ” and you will be in Utility mode.
fig.pnc
2
Press the keyboard key marked [PANIC] .
The indication “PNC ” starts blinking in the display.
fig.enter
3
Press the ENTER button.
* If you press a different button without pressing the ENTER button , the setting will be
cancelled.
The Reset message has been sent.
