114Installation and Service Guide: Color Controller E-46A
Troubleshooting
All replaceable parts are:
Present
Properly aligned
Installed securely
Installed on the appropriate site
The correct part for the system
Not visibly damaged
Chassis and contents have not been tampered with (no unauthorized
additions or changes have been made).
Chassis does not contain any foreign objects.
Chassis, page 47.
Motherboard, including components and traces, appears undamaged and
no foreign objects are evident.
CPU is present, installed in the correct connector, well-seated, and
appears undamaged.
CPU cooling unit is well-aligned and firmly attached.
CPU fan (including fan cable) is well-positioned, installed in the correct
connector, and appears undamaged.
Boards required on the motherboard are present, well-seated, and in the
correct slots.
Battery is installed.
Motherboard (with the motherboard
replacement dongle), page 59.
Important: When replacing the motherboard,
carefully review the cautions on page 63.
Each DIMM is well-seated and installed in the correct slot.
DIMM connectors are not oxidized (reseating removes oxidation).
DIMMs for E-46A, page 69
Each board required is:
Present
Installed in the correct slot
Well-seated
Appears undamaged
Required cables (if applicable) are:
Present
Firmly connected in the correct connectors
Not visibly damaged
Printer interface board, page 58
CPU is:
Present
Well-seated
Not visibly damaged
The CPU cooling unit is:
Ready for efficient thermal transfer
Well-aligned
Firmly attached
CPU with cooling assembly, page 70
Conditions to verify Part and additional page references
