Instruction Manual PMC-2
BA * PMC-2 * EN * 01/98 Page 83
PMC-2/02
I
NC
= 2A T
ambient
= 40°C
I
SC
= 4A ∆T
Case
= 60°C
Motor type
M
OM
M
NM
M
OD
M
ND
M
SD
n
NM
R
W100
K
M100
J
M
P
ND
P4.02 P4.08
Nm Nm Nm Nm Nm 1/min
Ω
Nm/A kgcm
2
kW A A
SB 0565006 0.78 0.67 0.78 0.67 3.31 5000 29.230 0.92 0.21 0.35 3.6 0.732
SB 0704005 0.68 0.65 0.68 0.65 2.84 4000 59.709 1.09 0.26 0.27 2.7 0.614
SB 0704010 1.25 1.14 1.25 1.14 4.35 4000 20.888 1.12 0.40 0.48 4 1.044
SB 0704015 1.71 1.49 1.71 1.49 4.42 4000 12.809 1.14 0.54 0.62 4 1.343
SB 0704020 2.22 1.85 2.22 1.85 4.48 4000 8.539 1.16 0.68 0.77 4 1.653
SB 0706005 0.68 0.61 0.68 0.61 2.84 6000 28.376 0.75 0.26 0.38 3.9 0.840
SB 0706010 1.24 0.99 1.24 0.99 3.02 6000 10.313 0.78 0.40 0.62 4 1.315
SB 0706015 1.70 1.22 1.51 1.22 3.02 6000 6.043 0.78 0.54 0.77 4 1.611
SB 0706020 2.21 1.40 1.58 1.40 3.17 6000 4.270 0.82 0.68 0.88 4 1.774
SB 1052002 2.94 2.88 2.94 2.88 8.41 2000 25.092 2.17 1.9 0.60 4 1.368
SB 1052004 5.23 5.01 4.35 4.35 8.70 2000 9.623 2.25 3.4 0.91 4 2
SB 1053002 2.95 2.82 2.93 2.82 5.86 3000 12.093 1.51 1.9 0.89 4 1.923
SB 1054002 2.95 2.72 2.23 2.23 4.46 4000 7.035 1.15 1.9 0.93 4 2
PMC-2/04
I
NC
= 4A T
ambient
= 40°C
I
SC
= 8A ∆T
Case
= 60°C
Motor type
M
OM
M
NM
M
OD
M
ND
M
SD
n
NM
R
W100
K
M100
J
M
P
ND
P4.02 P4.08
Nm Nm Nm Nm Nm 1/min
Ω
Nm/A kgcm
2
kW A A
SB 0565006 0.78 0.67 0.78 0.67 3.31 5000 29.230 0.92 0.21 0.35 3.6 0.732
SB 0704005 0.68 0.65 0.68 0.65 2.84 4000 59.709 1.09 0.26 0.27 2.7 0.614
SB 0704010 1.25 1.14 1.25 1.14 5.44 4000 20.888 1.12 0.40 0.48 5 1.044
SB 0704015 1.71 1.49 1.71 1.49 6.63 4000 12.809 1.14 0.54 0.62 6 1.343
SB 0704020 2.22 1.85 2.22 1.85 8.97 4000 8.539 1.16 0.68 0.77 8 1.653
SB 0706005 0.68 0.61 0.68 0.61 2.84 6000 28.376 0.75 0.26 0.38 3.9 0.840
SB 0706010 1.24 0.99 1.24 0.99 5.14 6000 10.313 0.78 0.4 0.62 6.8 1.315
SB 0706015 1.70 1.22 1.70 1.22 6.04 6000 6.043 0.78 0.54 0.77 8 1.611
SB 0706020 2.21 1.40 2.21 1.40 6.33 6000 4.270 0.82 0.68 0.88 8 1.774
SB 1052002 2.94 2.88 2.94 2.88 12.6 2000 25.092 2.17 1.9 0.60 6 1.368
SB 1052004 5.23 5.01 5.23 5.01 17.4 2000 9.623 2.25 3.4 1.05 8 2.304
SB 1052006 7.23 6.82 7.23 6.82 17.8 2000 5.820 2.30 4.8 1.43 8 3.061
SB 1052008 9.19 8.57 9.13 8.57 18.3 2000 4.210 2.36 6.2 1.79 8 3.752
SB 1053002 2.95 2.82 2.95 2.82 10.3 3000 12.093 1.51 1.9 0.89 7 1.923
SB 1053004 5.23 4.79 5.23 4.79 11.9 3000 4.473 1.53 3.4 1.50 8 3.230
SB 1054002 2.95 2.72 2.95 2.72 8.91 4000 7.035 1.15 1.9 1.14 8 2.440
SB 1054004 5.25 4.51 4.56 4.51 9.13 4000 2.627 1.18 3.4 1.89 8 3.950
