23.2.6 Detergent dispenser
Remove the worktop (see relevant paragraph).
Remove the control panel (see relevant paragraph).
Remove the pipes that connect it to the solenoid valve.
Lift the hook upwards that holds the steam vent pipe to the detergent
dispenser and remove the pipe.
Lift the detergent dispenser upwards.
Use pliers to slacken the clamp that holds the detergent loading pipe.
Remove the detergent loading pipe.
• Conveyor
Unhook all the hooks (shown by the arrows) that attach it to the detergent
dispenser.
Conveyor.
Technical Support - DMM 102/124 599 75 58-67 Rev.04
