• Sensor no. 2: TEMPERATURE (configurable)
See sect. 4.2.3.3 Sensor – LEDs and Display page 11
• Sensor no. 3: SPIN SPEED (configurable)
See sect. 4.2.3.3 Sensor – LEDs and Display page 11
• Sensor no. 4-5-6-7 (configurable)
See sect. 4.2.3.3 Sensor – LEDs and Display page 11
• Sensor no. 8-9
These two sensors are positioned under the display and act as:
Time manager
Allowing the end user to lengthen or shorten the washing cycle duration,
this adjustment should be done after setting the temperature value and
the spin speed.
• Sensor no. 10
This sensor has the START/PAUSE function, used to start up a washing
programme, after selecting the washing cycle and required options; it can
also pause a cycle that has already started: to allow you to change
selected option or open the door (if the temperature conditions or water
level allow for this).
The cycle re-starts if you touch the sensor again.
The Led combined with this sensor flashes slowly: in the selection phase,
during the pause and at the end of a cycle with water in the tub. It stays lit
when a cycle is running and turns off when the cycle has ended and the
door is unlocked.
While other sensors when touched immediately change from selected to de-selected, in the case of this sensor,
more time is needed to avoid unwanted cycle start ups or pauses.
Technical Support - DMM 18/124 599 75 58-67 Rev.04
