Electrolux EWX13611 - Page 66

Alarm
Code
Alarm Description Fault Condition Possible Fault Machine Action/Status Reset Key
E31
Electronic pressure
switch faulty
Frequency of electronic
pressure switch
out of limits
Pressure sensor defective
Wiring or main Board defective
Cycle blocked with door
locked
RESET
E32
Electronic pressure
switch
calibration problems
Frequency of electronic
pressure switch
not stable during draining
phase
Water inlet valve defective
Air trap system leaking
Pressure switch/sensor defective
Drain pipe blocked up
Blocked/dirty filter
Drain pump defective
Wiring or main board defective
Cycle Paused
START
RESET
E35 Water Overload
Overload pressure switch
on full state
for a time longer than 15
seconds
Water inlet valve defective
Air trap systems leaking
Pressure switch defective
Wiring or main board defective
Cycle blocked
Safety drain cycle.
Drain pump always in
operation (5 minutes ON,
5 minutes off, etc)
RESET
E38 Air trap system clogged
Water level doesn’t change
for at
least 30 sec. during drum
rotations
Air trap system clogged
Pressure sensor pipe clogged
Motor belt broken
Heating Phase skipped RESET
E41 Door opened
Door lock timeout expired
(20 seconds)
Door lock device defective
Wiring or main board defective
Cycle Paused
START
RESET
E42 Door lock device failure
Door still locked when
opening
(timeout of 4 minutes)
Door lock device defective
Wiring or main board defective
Current leakage between
heater element and earth
Cycle Paused
START
RESET
E43 Door lock device triac failure
Incongruence between
door lock device triac
sensing and
triac status
Door lock device defective
Wiring or main board defective
Safety Drain cycle activation.
Cycle blocked
RESET
E44 Door closed sensing failure
Wrong input signal to
microprocessor
Main board defective
Safety Drain cycle activation.
Cycle blocked
RESET
E45 Door triac sensing failure
Wrong input signal to
microprocessor
Main board defective
Safety Drain cycle activation.
Cycle blocked
RESET
E51
Motor power triac short-
circuited
Current leakage from motor or from wiring; Main PCB faulty;
Cycle stops with door open
(after 5 attempts)
ON/OFF
E52 Tachometer faulty
Bad or no signal from
tachometer
Motor defective
Motor Wiring or Motor Control board defective
Cycle blocked after 5 attempts
with door locked
ON/OFF
RESET
E53
Motor triac “sensing” circuit
faulty (incorrect
microprocessor input
voltage)
Main circuit board faulty. Cycle blocked RESET
E54
Motor relay contacts sticking
(voltage level high when the
relay switches to OFF)
Current leakage from motor or from wiring; Main PCB faulty;
Cycle blocked
(after 5 attempts)
RESET
Technical Support - DMM 66/124 599 75 58-67 Rev. 04
