SOI/DT 2006-01 dmm 24/71 599 37 47-13
4.5 Washing groups
The washing group is suspended from the support crosspiece by two helical springs.
The oscillation of the washing group is absorbed by the two dampers attached to the lower crossbars.
Balancing of the washing group is provided by a front counterweight in cement and by a rear counterweight.
4.5.1 Types of washing groups
The washing machines may be fitted with washing groups of varying dimensions and spin speeds.
WASHING GROUPS
Load capacity (cotton)
Type
Max.
Drum volume
G19
5 Kg 42 l
G20
6 Kg 46 l
G22
7 Kg 54 l
G23
8 Kg 63 l
Spin speed Residual humidity Efficiency of spin
400
500
800
1000
1200
1400
1600
1800
85 %
78 %
66 %
60 %
53 %
52 %
44 %
42 %
F
E
D
C
B
B
A
A
CARBORAN
