SOI/DT 2006-01 dmm 63/71 599 37 47-13
6.2.6 Drain filter pump body
a. Detach the hoses.
b. Remove the screw which secures it to the crosspiece.
c. Push it towards the interior of the appliance.
d. Lift it up (as indicated by the arrow) and remove.
e. While re-assembling, pay attention that the rubbers are
positioned correctly.
d
b
c
d
