Electrolux T3900 - Technical Data, Type T3900

487 03 29 41
3
2. Technical data
Service
manual
2
Technical data - type T3900
Heating Gas Steam Electric
Drum volume: 900 litres 900 litres 900 litres
Weight net: Basic: Standard door 440 kg 440 kg 440 kg
Basic: Sliding Door 494 kg 494 kg 494 kg
Heating unit 39 kg 50 kg 42 kg
Motors: Effect: Fan (3-phase) 1.1 kW 1.1 kW 1.1 kW
RPM: 50 Hz 2800 rpm 2800 rpm 2800 rpm
RPM: 60 HZ 3400 rpm 3400 rpm 3400 rpm
Effect: Drum (3-phase) 1.5 kW 1.5 kW 1.5 kW
RPM: 50 Hz 1440 rpm 1440 rpm 1440 rpm
RPM: 60 Hz 1730 rpm 1730 rpm 1730 rpm
Drum: Diameter 1240 mm 1240 mm 1240 mm
Depth 770 mm 770 mm 770 mm
Revolutions per minute 38 rpm 38 rpm 38 rpm
Capacity: 45 kg 45 kg 45 kg
Heat effect: Gas heating 64 kW
Steam heating
Electric heating 48 / 60 kW
Air consumption: Max. 2300 m
3
/h Max. 2300 m
3
/h Max. 2300 m
3
/h
Piping: Exhaust duct Ø 315 mm Ø 315 mm Ø 315 mm
Gas connection ISO 7/1 - Rp 1
Steam in ISO 228/1 - G1
Steam out ISO 228/1 - G1
Pressure drop: max. 100 Pa max. 100 Pa max. 100 Pa
Gas pressure: See page regarding pressure in the installations manual supplied with the dryer
Sound pressure level: < 70 dB (A) < 70 dB (A) < 70 dB (A)
Depending upon
steam pressure
