2. Technical data
Service
manual
487 03 29 41
4
2
Technical data - type T31200
Heating Gas Steam Electric
Drum volume: 1200 litres 1200 litres 1200 litres
Weight net: Basic: Standard door 470 kg 470 kg 470 kg
Basic: Sliding Door 524 kg 524 kg 524 kg
Heating unit 46 kg 50 kg 42 kg
Motors: Effect: Fan (3-phase) 1.1 kW 1.1 kW 1.1 kW
RPM: 50 Hz 2800 rpm 2800 rpm 2800 rpm
RPM: 60 HZ 3400 rpm 3400 rpm 3400 rpm
Effect: Drum (3-phase) 1.5 kW 1.5 kW 1.5 kW
RPM: 50 Hz 1440 rpm 1440 rpm 1440 rpm
RPM: 60 Hz 1730 rpm 1730 rpm 1730 rpm
Drum: Diameter 1240 mm 1240 mm 1240 mm
Depth 1000 mm 1000 mm 1000 mm
Revolutions per minute 38 rpm 38 rpm 38 rpm
Capacity: 60 kg 60 kg 60 kg
Heat effect: Gas heating 82 kW
Steam heating
Electric heating 60 / 72 kW
Air consumption: Max. 3000 m
3
/h Max. 3000 m
3
/h Max. 3000 m
3
/h
Piping: Exhaust duct Ø 315 mm Ø 315 mm Ø 315 mm
Gas connection ISO 7/1 - Rp 1
Steam in ISO 228/1 - G1
Steam out ISO 228/1 - G1
Pressure drop: max. 100 Pa max. 100 Pa max. 100 Pa
Gas pressure: See page regarding pressure in the installations manual supplied with the dryer
Sound pressure level: < 70 dB (A) < 70 dB (A) < 70 dB (A)
Depending upon
steam pressure
