11. Maintenance
Service
manual
487 03 29 41
6
11
487 03 29 41
Maintenance - Internal wearing
parts
Maintenance should be conducted to an
extent related to operation frequency and the
conditions on the premises, or at least once
a year.
Cleaning around the drum
1. Disconnect the power supply to the dryer.
2. Dismount the front panel
(see section 42: Drum with bearing).
3. Remove the lint using a vacuum cleaner,
fig. 1.
4. Inspect the two supporting rollers and
replace them if necessary.
Cleaning the component unit
The component unit must be checked for lint
and if necessary vacuumed carefully.
1. Dismount the back plate and vacuumed
carefully, fig. 2.
2. Reassemble the dryer.
3. Connect the power supply.
4. Function check the dryer.
Dryer with RMC
To ensure that the moisture tracing is always
working optimally it is important to clean the lifters.
Lack of cleaning the lifters can reduce the
automatic residual moisture control in the clothes
resulting in the clothes being moister than
requested when the program has ended.
Cleaning
Wipe off/clean drum and lifters with citric acid
(Acidum citricum). If soap/softener residue
remains, it is recommended also to use a coarse
sponge.
The frequency of cleaning should depend on the
operating frequency - with a minimum of once a
week.
Remove all accumulated lint
1
2
