Electrolux T3900 - Control Unit with Main Circuit Board

487 03 29 41
5
21. Controls
Service
manual
21
487 03 29 41
Behind the back plate:
Control unit with main circuit board
and supply disconnector
Control unit with main circuit board
Dryer with standard loading door
Fig. 1 Control unit is placed behind the rear panel.
1
Main circuit board
Supply disconnector
Thermal motor
overload relays
Internal control fuses,
on electric heated
dryers only
