11. Maintenance
Service
manual
487 03 29 41
4
11
487 03 29 41
Maintenance
Exhaust duct
Check that the exhaust duct on the back of the
dryer has not become blocked with lint or other
debris (after three months, then every three to
six months, as required).
Nonreturn flap in evacuation pipe
If the evacuation pipe has a nonreturn flap (2
dryers on a shared evacuation pipe), it must be
cleaned at least once quarterly .
Check that the flap is working.
Fan
After six months check that the fan has not
become blocked with lint or other debris, then
once every year, as required. Be careful not to
damage the fan wheel.
Door gasket
Standard door:
Check that the loading door gasket is clean
and in good condition. Use a suitable cleaner.
Do not use solvents that may damage sensitive
plastics or painted finish.
Check that the gaskets are clean and give a
tight seal.
Sliding Door:
Cleaning as for Standard door.
Check that felt gasket A is intact and in good
condition.
There may be a maximum of 2 mm between
steel frame and felt, fig. 1.
The 2 doors must close parallel and the rubber
B gasket must be intact, fig. 2.
Defective gaskets must be replaced.
If the doors need to be adjusted,
see section 43.
1
2
A
A
Max. 2 mm
B
