2. Technical data
Service
manual
487 03 29 41
6
2
Technical data - type TD135
Heating Gas Steam Electric
Drum volume: (1200 litres) 42.4 cu.ft 42.4 cu.ft 42.4 cu.ft
Weight net: Basic: Standard door (470 kg) 1036 lb 1036 lb 1036 lb
Basic: Sliding Door (524 kg) 1153 lb 1153 lb 1153 lb
Heating unit 101 lb (46 kg) 110 lb (50 kg) 93 lb (42 kg
Drum: Diameter (1240 mm) 48 13/16” 48 13/16” 48 13/16”
Depth (1000 mm) 39 3/8” 39 3/8” 39 3/8”
Revolutions per min 38 rpm 38 rpm 38 rpm
Capacity: (60 kg) 135 lb 135 lb 135 lb
Heat effect: Gas heating (82 kW) 280000 BTU/h
Steam heating Depending upon
steam pressure
Electric heating (60 kW) 205000 BTU/h
Electric heating (72 kW) 240000 BTU/h
Air consumption:Gas max (3000 m
3
/h) 1765 cu.ft / min
Steam max (3000 m
3
/h) 1765 cu.ft / min
Electric. max (3000 m
3
/h) 1765 cu.ft / min
Piping: Exhaust duct (Ø 315 mm) Ø 12” Ø 12” Ø 12”
Piping: Gas connection 1” NPT
Steam in ISO 228/1 - G1
Steam out ISO 228/1 - G1
Max. counter-pressure: (100 Pa) 0.37” W.C 0.37” W.C 0.37” W.C
Gas pressure: See page regarding pressure in the installations manual supplied with the dryer
Sound pressure level: < 70 dB (A) < 70 dB (A) < 70 dB (A)
