29. Door switch and filter switch
Service
manual
487 03 29 41
4
29
Testing door switch
Standard door
1. Connect the power supply to the dryer.
2. Start the dryer.
3. Fig. 1 Check that the fan, drum rotation
and heat all stop when the door is opened
max. 40 mm.
Fig. 2 If it is possible to open the door more than 40
mm before the dryer stops, it is necessary to adjust the
activating pin on the door.
2
1
40 mm
