30. Motor
Service
manual
487 03 29 41
4
30
Voltage/
frequency
V/Hz
Heat
effect
kW
Fuse
size
A
200-240V 3AC 50/60Hz 48kW 20A
400-480V 3AC 50/60Hz 48-60-72kW 16A
440-480V 3AC 60Hz (USA) 48-60-72kW 15A
Internal fuses on electric
heated dryers
Internal control
On electric heated dryers the internal
control is protected by internal fuses
A located in fuse retainers B on the
supply disconnector, fig. 1.
Fuse sizes are in the table below,
fig. 2.
A
B
2
Electric heating
