MP500/4N-8-16 Installation
For further information, see also paragraph 1.2.3 Maximum system size.
Note 1) If the battery is not connected to the terminals of the connection cables, (red and black Faston) there is no power.
Note 2): remotely assisted system with guaranteed intervention in case of lack of power;
Note 3) in case of blackout, the +SR does not supply voltage.
8.3 MP500/16 CONTROL PANEL
Mains power supply
100 - 240 V~ -15/+10%, 50/60 Hz
Max. absorption current (PS534 – MW RS-50-15)
1.3 A
PS534 (MW RS-50-15) power output nominal voltage - Type A power supply
14.4 V⎓
Max current deliverable PS515 (MW RS-50-15) power supply
3.4 A
Ripple max PS534 (MW RS-50-15)
150 mV p.p. with I = 3,4 A
Control panel operating voltage
10.5 V⎓ to 16 V⎓
Overload protection tripping current
16 V⎓
Max current absorbed by control panel board at 12 V⎓
(with relays energised, default condition)
85 mA stand-by with balanced inputs
Max current absorbed by the control panel board ( with relays de-energised)
65 mA with balanced inputs
Installable battery
12 V – 18 Ah
Nominal voltage of battery charger note 1)
13.8 V⎓
Max current supplied to charge battery
850 mA
Max time for recharging battery to 80%
24 hours
Battery flat threshold
11.5 V
Battery release threshold
10.5 V
Automatic test battery
every 24 hours (with mains)
Max current for external devices (keypads, sensors, sirens):
taken from +, +V1, +V2 terminals
Degree 3 – with ATS4 dialler and 60 hours autonomy
(total 260 mA, of which 85 mA for the control panel)
Degree 3 – with ATS4 dialler and 30-hour autonomy note 2)
(total 520 mA, of which 85 mA for the control panel)
Degree 2 – with ATS2 dialler and 12 hour autonomy
(total 1150 mA, of which 85 mA for the control panel)
175 mA
435 mA
1065 mA
Nominal voltage on the +SR terminal note 3)
14.4 V⎓
Max current deliverable from the +SR terminal
200 mA (with overload protection)
Nominal voltage on the + terminal
13.8 V⎓ ±1.5%
Max current deliverable from + terminal
1100 mA (with overload protection)
Nominal voltage on the +V1 terminal
13.8 V⎓ ±1.5%
Max current deliverable from +V1 terminal
750 mA (with overload protection)
Nominal voltage on the +V2 terminal
13.8 V⎓ ±1.5%
Max total current deliverable from the +V2 terminals
750 mA (with overload protection)
Ripple max on outputs +SR + +V1 +V2 with flat battery
150 mV (1.1%)
Max current and voltage of relay contact switch of outputs U1 and U2
1 A – 24 V⎓ with resistive load
Max current deliverable from electric output U3
100 mA
Max current deliverable from electric outputs U4, U5, U6
10 mA
Tamperproof switch
1 A – 24 V⎓
Max total length of control panel-peripheral serial Bus line
400 m
Max length of the audio line (audio bus)
300 m with twin telephone line
Max length of the connection between each sensor or actuator and the control panel
500 m
Max length of the connection between a fast sensor (roller, shock, ...) and the
control panel
100 m
Max number possible code combinations
from 10,000 to 1,000,000
Number of possible combinations of DK50 electronic keys
more than 1099 billion
Number of possible combinations of DK30 proximity keys
more than 4 billion
Number of possible combinations of DK70 proximity keys
more than 4 billion
Programmable time entry
5 s to 5 minutes
Programmable exit entry
5 s to 5 minutes
Programmable alarm time
30 s to 15 minutes (default 3 minutes)
Programmable tamper alarm time
30 s to 15 minutes (default 3 minutes)
Failure signal
optical (LED) and electric for control panel battery low,
fuses, low power supply expansion boards
Type of memory for programming, Events log, and diagnose log maintenance
Data Flash
Certified functioning time (EN50131 – Environmental class II, general internal)
-10°C to +40°C
Average relative humidity during operation
75%
Storage temperature
-20°C to +60°C
